Factory supply customized Metal parts by lost-foam investment casting
Product Description
| Item | Description | Material | Technical Process |
| 1 | Ductile iron castings | ASTM A 536-Gr.60-40-18, 65-45-12 | Green-sand moulding |
| DIN-GGG40, GGG50, GGG60, GGG70 | Resin-sand moulding | ||
| JIS-FCD40, FCD50, FCD60, FCD70 | Lost foam cast | ||
| BS-Gr370-17,Gr420-12, Gr500-7 | Shell-core cast | ||
| NF-FGS370-12, FGS400-12, FGS500-7 | Electric-furnace smelting | ||
| 2 | Grey iron castings | ASTM A48-No.20,25,30,35,40,45 | Green-sand moulding |
| ASTM A126-Class A, Class B, Class C | Resin-sand moulding | ||
| DIN-GG10, GG15, GG20, GG25, GG30 | Lost foam cast | ||
| JIS-FC10, FC15, FC20, FC25, FC30, FC35 | Shell-core cast | ||
| BS-Grade 150, 180, 220, 260, 300, 350 | Electric-furnace smelting | ||
| NF-FGL150, FGL200, FGL250, FGL300 |
| ||
| 3 | Carbon steel castings | ASTM A216-Cr. WCB. Cr. WCA, Gr. WCC | Soluble glass sand moulding |
| ASTM-415-205, 450-240, 485-275, 80-40 | Resin-sand moulding | ||
| DIN-GS-C25, GS-38, GS-45, GS-52 | Lost wax casting | ||
| JIS-SC410, SC450, SC480,SCC5 | Lost foam cast | ||
| NF-GE230, GE280, GE320, GE370 | Shell-core cast | ||
|
| Electric –furnace smelting | ||
| 4 | Stainless steel castings | ASTM-CF-8M,CF-8, CA-15, CA-40,316, | Soluble glass sand moulding |
| DIN-G-X6 CrNi18 G-X7Cr13 | Resin-sand moulding | ||
| JIS-SCS13, SCS1, SCS 2, SCS 14A | Lost wax casting | ||
| BS-304 C15, 410C21, 420C29, 316 | Lost foam cast | ||
| NF-Z6CND18.12M, Z6CN18.10M,Z12C13 | Shell-core cast | ||
|
| Electric –furnace smelting | ||
| 5 | Alloy steel castings | DIN-GS-40Mn5, GS-20Mn5, GS-37MnSi5 | Soluble glass sand moulding |
| JIS-SCMn3, SCW480, SCSiMn2,SCCrM3 | Resin-sand moulding | ||
| ASTM-LCC | Lost wax casting | ||
| UNS-J02505, J13048 | Lost foam cast | ||
| NF-G20M6, G35CrMo4 | Shell-core cast | ||
|
| Electric –furnace smelting |
| Item | Description |
| Service | OEM / ODM or Sample Production |
| Process Technology | lost wax casting process / soluble glass casting process / silicasol casting process/ Die Casting process /Sand Casting process / + Precision CNC Machining + Surface Treatment |
| Material we can cast | (1)grey iron, ductile iron , pig iron |
| (2)carbon steel, stainless steel, alloy steel | |
| (3)aluminum alloy, aluminium, A380, aluminum 6061 | |
| (4)zinc alloy ,copper, brass, bronze etc | |
| Size | Customized as customer's drawings |
| Weight Range | 0.02-50 KGS |
| MOQ | 500 Pieces |
| Tolerance | ±0.02mm |
| Surface Treatment | Heat Treatment, Polishing, Plating, Machining, Anodizing, shot, sand blasting, zinc plated, oxide, galvanized etc. |
| Testing | Three coordinate measurement machine for testing. |
| Certification | ISO9001:2008 |
| Standard | ISO , DIN, AISI, ASTM, BS, JIS, etc. |
| Process Techonology | Material |
| Investment casting | ASTMA148class80-40, ASTMA148Class80-50 A572GR60, AISI316 stainless steel, ST52, S355, GS-52.3, ASTMA48Class30B CK45, 1.7218-25CrMo4 |
| Sand casting | GGG50,GGG30, ASTMA48 class25B, 42CrMo4, C22 ductile iron 65-45-12, AlCuMgpbF34, EN-JIS-500-7 EN1563 , EN10293-GE300 HT200, DIN17205-GS-25CrMo4 |
| Die casting | C1040, A356, A380,AISI12 |
| Stamping parts | Steel , alloy , Aluminum or as above |
| Forging | Steel , alloy , Aluminum ,Zinc , Copper , Brass ,or other as above |
| CNC Machining | Steel , alloy , Aluminum ,Zinc , Copper , Brass ,or other as above |
Engaged in the casting industry for 11 years, our foundry has built up the complete production lines and quality control systems. We supply OEM service and exports to Germany, Japan, USA, Canada, Korea, New Zealand, and so on. OEM /ODM Custom Service | SGS / TUV / ISO 9001:2008 Certified | Over 11 Years' Casting Experience | Clients in over 70 countries cooperate with us | Testing Equipment N
Customer Visit
FAQ FAQ: 1 . How to contact with your company? Please send email to " tll@ qdtll.cn" 2 .What does your company need to submit a quotation? Drawing or sample, together with relevant information, such as quantity, weight, material. 3. Which kind of format of the drawing? PDF, IGS, DWG, STEP, etc 4 . What if we do not have a drawing? We can duplicate your sample and make drawing for your confirmation. 5. How soon before I get a sample? weeks for mold and sample, 3-7 days for express. 6. How can we quote for you? As our factory only supply OEM service(custom service) Please send us enquiry by email, with all the technical drawings you have, with all of your requirements, such as material grade, tolerance, machining demands, surface treatment, heat treatment, mechanical property requirements, etc. Our specialized engineer will check and quote for you, we would appreciate the opportunity and will respond in 3-5 working days or less. It is also best if you can provide a sample, we can also quote depends on the sample. Contact us if you need more details on Lost Foam Casting. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Custom Manufacturing Metal Parts、Steel Casting Ceramic Foam Filter. If these products fail to match your need, please contact us and we would like to provide relevant information. Product Categories : Lost Wax Castings
